A pull-up bar for a wide door frame: two bars reach 36 in., and then you run out

Why wide is the awkward size

A leverage doorway bar works by hooking over the casing on the far side of the door and bracing against the wall on the near side. Your weight on the bar tries to rotate it, and the brace resists. Widen the opening and two things get worse at once: the bar between the uprights is a longer unsupported span, and the moment arm on the upper hook is longer, so more force goes into the trim.

That is why most bars stop at 32 in. — it is not laziness, it is where the geometry stops being comfortable. The bars that extend to 36 in. do it with a longer telescoping center section and higher ratings, and the sensible response as a buyer is to take the higher rating seriously rather than treating it as a marketing number.

Measure these three things first

• Clear opening width. Inside face of trim to inside face of trim, at the top of the door where the bar will sit. Not the door slab width, and not the rough opening.
• Trim depth, front to back. Standard casing is about 3.5 in.; the KAKICLAY and AmazeFan are specified for that. Deep or ornate casings — common in older houses and in period conversions — need a bar designed for it, which is where the Perfect Fitness Multi-Gym Pro and its up-to-6-in. capability comes in.
• Trim height above the door, and what is above it. The upper bracket needs a few inches of solid wall or trim above the opening. A transom window, a plaster cornice or a door that reaches almost to the ceiling will stop a bar that fits the width perfectly.

While you are measuring, check the trim is actually solid. Thin applied molding pinned to drywall is the most common reason a bar that fits does damage anyway — the damage page covers what to look for and how to spread the load.

The four, side by side

Why the KAKICLAY leads

It has the widest range here (21.7 to 36.2 in.) and the highest rating of any doorway bar on this site at 440 lb, which is exactly the combination a wide opening needs. Multi-grip positions are a bonus. It is specified for trim up to 3.5 in., so check your casing.

The AmazeFan reaches the same 36.2 in. maximum at 400 lb and folds, which is the better pick if the bar has to come down and go in a cupboard between sessions. At a wide setting the 40 lb of rating difference is worth having, so the KAKICLAY edges it for anyone over about 200 lb.

The deep-casing case

Wide and deep are different problems and people conflate them. A 33 in. opening with 5 in. of ornate Victorian casing is not solved by a bar that extends to 36 in. and expects 3.5 in. of trim — the hook will not seat. The Perfect Fitness Multi-Gym Pro handles openings up to 33 in. and casings up to 6 in. deep, with padded frame guards that spread the load. Its 300 lb rating is the lowest here, so it is the right answer only when the depth is the actual constraint.

Over 36 in.: stop looking at doorway bars

Double doorways, archways, cased openings and wide openings between rooms are all above what any leverage bar covers, and no amount of searching will turn one up. Two honest answers:

Free-standing. The BaseBlocks Big Bar is an 81 in. full-height bar rated 660 lb that folds from 59 x 35 in. down to 29 x 35 in. for storage — the only full-height free-standing bar here that genuinely stores away, which matters in the kind of home that has wide openings and no spare room. The alternatives, including the multi-station frames, are in the free-standing roundup and the power tower roundup.

Mounted. If you can drill, a wall or ceiling bar sidesteps the whole problem and is rated far higher — the wall-mounted page covers it. That is obviously not an option for most renters, which is why this page exists.

Fitting a bar in a wide opening

Extend the bar so the uprights sit as close to the inside faces of the trim as they will go — a bar floating in the middle of a wide opening puts all the load on a short length of casing. Seat the upper hook fully over the trim and check it is flat against it, not riding on a paint edge or a bead. Then hang with your feet still on the ground and put weight on progressively before committing.

Check it every session. Leverage bars in wide openings work loose faster than in narrow ones, and a bar that has shifted half an inch is the one that comes off the trim. The no-screw page has the full routine for living with a leverage bar.

How this list was built

We read fitted width range, specified trim depth, mounting type and rated load off each maker's own listing, then scored on the pull-up bar rubric — fit and clearance 25%, reversibility 25%, rated load and build 20%, grip options 15%, value 15%. "Fit and clearance" here means the published width range and trim depth, and anything that stops at 32 in. was excluded from the doorway section regardless of how good it is elsewhere — which is why the Iron Gym, ProsourceFit and Ally Peaks bars that rank on our doorway roundup do not appear here. No bars were tested in a lab; we own no lab and say so on our methodology page.
